7782 Four Channel Position
Home> Products > 7782 Four Channel Position
7782
  • 7782

7782

Item No.: 7782
The 7782 are multi-channel condition monitoring systems. They are specifically designed for ease of use and each channel can independently set to be used to measure displacement.
Add to Inquiry
Description
Inputs
__ Thrust Position
__ Differential Expansion

4 channels of:
• Eddy current transducer signals
• Accelerometer signals
• Voltage signals from any dynamic measurement device, such as a velocity or pressure transducer

Transducer Power:
• Constant voltage (-24V dc)
• Constant current
(4.5mA ±20% from +24V dc)
• None (voltage input)
Tachometer may be powered, constant voltage, or configured as voltage input.

Voltage Range:
-24V ~ +24V

Frequency range:
1 Hz to 20 kHz

Input Impedance:
>50kΩ
Speed/Frequency Range:
1 to 1, 200, 000 RPM
0.0167 to 20, 000Hz

Speed measurement error:
1 to 12, 000 RPM +/- 1 RPM
12, 001 to 120, 000 RPM +/- 6 RPM
120, 001 to 1, 200, 000 RPM +/- 50 RPM
