7766 Six Channel Temperature
Home> Products > 7766 Six Channel Temperature
7766
  • 7766
  • 7766
  • 7766
  • 7766
  • 7766

7766

Item No.: 7766
The 7766 are Six Channel Temperature monitoring systems. They are specifically designed for ease of use and each channel can independently set to be used to measure temperature.
Add to Inquiry
Description
Inputs:
•Signal: Accepts from 1 to 6 RTD or TC transducer signals.
•Input Impedance: Greater than 10 MΩ for each lead input.

Environmental Limits:
• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
                                      when used with Internal/External Termination Keyphasor I/O Module.
• Operating Temperature: 0°C to +65°C (32°F to +150°F)
                                      when used with Keyphasor Internal Barrier I/O Module (Internal Termination).
• Storage Temperature: -40°C to +85°C (-40°F to +185°F).

Transducers:
• Type E:  -100°C to 1000°C,(-148°F to 1832°F).
• Type J:  0°C to 760°C,(32°F to 1400°F).
• Type K:  0°C to 1370°C,(32°F to 2498°F).
• Type T:  -160°C to 400°C,(-256°F to 752°F).

Voltage Compliance (current output):
0 to +12 Vdc range across load.
Load resistance is 0 to 600 Ω.

Resolution:
0.3662 μA per bit ±0.15% error at room temperature ±0.4% error over temperature range.
